Aluminum Material Timing Belt Pulley HTD3M Type

HTD 3M standard timing pulleys are the primary type of HTD pulleys. The HTD 3M standard timing pulleys are designed for all types of HTD and RPP belts with a tooth pitch of 3.00 mm. They are typically used in machine tools, small machinery, compressors, packaging, printing machines, the food, paper, and chemical industry, and many other devices.

Category:
Description

HTD 3M standard timing pulleys

HTD 3M standard timing pulleys are the primary type of HTD pulleys.
They are made of steel or gray cast iron and designed as unbored or with a pilot bore.

HTD 3M Pulleys Fields of Use

The HTD 3M standard timing pulleys are designed for all types of HTD and RPP belts with a tooth pitch of 3.00 mm.
They are typically used in machine tools, small machinery, compressors, packaging, printing machines, the food, paper, and chemical industry, and many other devices.

Products Specification

Product Name
Timing Belt Pulleys
Teeth profile
Trapezoidal toothed
MXL, XXL, XL, L, H, XH, XXH
T-toothed
T2.5, T5, T10, T20
Arc toothed
HTD3M, HTD5M, HTD8M, HTD14M, HTD20M, Gt1.5,Gt2, Gt3, Gt5
S-toothed
S2M, S3M, S4.5M, S5M, S8M, S14M
Parabolic-toothed
P2M, P3M, P5M, P8M, P14M
Teeth Quantity
10-150 teeth or customized
Inner Bore
2-200mm H7 precision or customized
Belt width
4mm, 6mm, 9mm, 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm,
1/4”, 5/16”, 3/8”, 1/2”, 3/4”, 1”, 1.5”, 2”or customized
Application
3D printer, Automation equipment, Power transmission, Embroidery machine, etc.
Accessories
We can provide the service of assembling setscrews, bearings, shafts, or taper bush.
Surface treatment
Anodize, Black Oxide, Phosphate, and Galvanization
Material
Aluminum,Steel,Stainless steel,POM,Plastic,Nylon

Advantages of Aluminum Material Timing Belt Pulley

An aluminum material timing belt pulley is designed to fit on the synchronous belt drive of a car. This type of pulley features a D-shaped or round hole. It is made of an aluminum alloy and has 60 teeth. It is easy to install and does not need additional drilling or assembly. In addition, it is very time-saving. And it can be used on a car without damaging it.
When choosing the material for the timing belt pulley, consider its weight. Aluminum is lightweight compared to steel and plastic. However, aluminum pulleys are expensive. Plastic is more affordable and requires less maintenance than steel. And since aluminum is malleable, you can customize it to meet your needs.
Another benefit of an aluminum timing belt pulley is its corrosion resistance. Aluminum reacts with oxygen to form a protective oxide layer. This means that you will need to replace your pulleys less often than you would with other metals. Plus, they are also more environment-friendly. In addition, aluminum pulleys are perfect for heavy-duty applications and hot-weather environments.
The main benefits of an aluminum timing belt pulley include long operational life, low maintenance, and high strength. Aluminum is also light in weight and offers improved positional accuracy. It also demonstrates excellent wear resistance and is great for high-power drive systems. It is also thermally conductive.

Other Type Timing Belt Pulley



Customization Process

Step 1. Information: Please provide information on customized materials and sizes to us.
Step 2. Quotation: Quote price after making standard engineering drawings.
Step 3. Order Confirmed: Confirm quotation, confirm sample, then make a purchase order.
Step 4. Production: Put into production with high efficiency and control quality.
Step 5. Packing & shipping: Pack and ship according to requirement.
Step 6. After-sale service: Receiving and evaluation, deep cooperation.
