Nylon conveyor belt
Characteristics
Nylon(Nylon conveyor belt) is the best in the composite fibers working in the rubber industry, is of a structure braided by nylon fibers in warp and weft, and has the widest application, with outstanding advantages of excellent wear resistance, high strength and good fatigue resistance.
The conveyor belt is making from nylon canvas is featured by thin belt body, high strength, impact resistance, good trough formation property, large bonding force among layers, excellent flexibility and long service life, is suitable for conveying materials in medium and long distance and high transmission capacity at a high speed, and is widely applicable to such departments as mines, metallurgy, construction, ports and the like.
Specification and technical data of multi-ply nylon conveyor belt
Fabric type | Fabric structure | Fabric specs | Ply
thickness (mm/p) |
(N/mm) Strength series | (mm)
Cover Rubber thickness |
Width mm | Length
m |
||||||
Warp | Weft | 2ply | 3ply | 4ply | 5ply | 6ply | Upper | Lower | |||||
Nylon
(NN) |
Nylon
(N) |
Nylon
(N) |
NN-100 | 0.75 | 200 | 300 | 400 | 500 | 600 | 1.5-8 | 0-4.5 | 400-1800 | ≤ 300 |
NN-150 | 0.80 | 300 | 450 | 600 | 750 | 900 | |||||||
NN-200 | 0.90 | 400 | 600 | 800 | 1000 | 1200 | 500-1800 | ||||||
NN-250 | 1.15 | 500 | 750 | 1000 | 1250 | 1500 | |||||||
NN-300 | 1.25 | 900 | 1200 | 1500 | 1800 | ||||||||
NN-400 | 1.45 | 1600 | 2000 | 2400 | 800-1800 | ||||||||
NN-500 | 1.55 | 2000 | 2500 | 3000 |
Cover properties of the belts
Cover grade | Tensile strength ≥ | Elongation at break ≥ | Abrasion
≤ |
Change rate of tensile strength and elongation after aging | |
Mpa | kgf/cm2 | % | cm3/1.61km | % | |
Heavy(H) | 18 | 180 | 400 | 0.7 | -25~+25 |
Medium(M) | 14 | 140 | 350 | 0.8 | -25~+25 |
Light(L) | 10 | 100 | 300 | 1.0 | -30~+30 |
Adhesion and elongation of the belt
Belt carcass | adhesive strength | Elongation | |||
Between plies N/mm | Between rubber and carcass | Longitudinal elongation at break % ≥ | Longitudinal
elongation %≤ |
||
1.5mm Rubber thickness ≤ 1.5mm | > 1.5mm Rubber thickness > 1.5mm | ||||
Nylon canvas | ≥ 4.50 | ≥ 3.15 | ≥ 3.50 | 10 | 20 |
