Stainless Steel Worm Gear for CNC Machinery
- Produce strictly following ANSI or DIN standard dimension
- Material: 1045 Carbon Steel
- Bore: Finished bore
- Module: 1~3
Stainless Steel Worm Gear Description
Stainless Steel Worm Gear Main Features:
- Produce strictly following ANSI or DIN standard dimension
- Material: 1045 Carbon Steel
- Bore: Finished bore
- Module: 1~3
Product Parameters
Product Parameters| Product name | Worm Gear and Worm Wheel |
| Materials Available | Stainless Steel, Carbon Steel, Brass, Bronze, Iron, Aluminum Alloy,Copper,Plastic,Nylon,PA66,MC,PEER,MSM,POM,Derlin etc |
| Heat Treatment | Quenching & Tempering, Carburizing & Quenching, High-frequency Hardening, Carbonitriding…… |
| Surface Treatment | Carburizing and Quenching, Tempering ,Tooth surface high quenching Hardening, Tempering |
| BORE | Finished bore, Pilot Bore, Special request |
| Processing Method | Molding, Shaving, Hobbing, Drilling, Tapping, Reaming, Manual Chamfering, Grinding, etc |
| Pressure Angle | 20 Degree |
| Hardness | 55- 60HRC |
| Size | Customer Drawings & ISO standard |
| Package | Wooden Case/Container and pallet, or made-to-order |
| Certificate | ISO9001:2008 |
| Applications | Electric machinery, metallurgical machinery, environmental protection machinery, electronic and electrical appliances, road construction machinery, chemical machinery, food machinery, light industrial machinery, mining machinery, transportation machinery, construction machinery, building materials machinery, cement machinery, rubber machinery, water conservancy machinery and petroleum machinery |
| Machining Process | Material preparation, normalizing, rough turning, quenching and tempering, semi-fine turning outer circle, rough turning spiral surface, fine turning (fine grinding) inner hole end face, keyway, semi-fine turning spiral surface, pliers (rest incomplete teeth), semi-fine grinding outer circle, semi-fine grinding spiral surface, grinding center hole, delicate grinding outer ring, fine scratching helical surface, finished product inspection. |
| Advantages | 1. Produce strictly following ANSI or DIN standard dimension 2. Material: SCM 415 steel 3. Bore: Finished bore 4. Precision grade: DIN 5 to DIN 7 5. Surface treatment: Carburizing and Quenching 6. Module: From 1 to 4 7. Tooth: From Z15 to Z70 |
Specification:
| Number | Number of Teeth | Shaft Bore Dia. AH7 (1mm Increment) | Twisting Direction | B | C | D | E | F | G | ||
| Type | Module | Straight Bore Straight Bore+Tap | Keyway+Tap | ||||||||
| Straight Bore
Straight Bore+Tap Keyway+Tap |
1.0 | 20 | 6 | 8 | L(Left)
R(Right) |
17 | 20 | 22 | 8 | 10 | 18 |
| 22~ 28 | 8 | 8~13 | 18~20 | 22~28 | 24~30 | ||||||
| 30~48 | 10 | 10~17 | 25~30 | 30~48 | 32~50 | ||||||
| 50~70 | 12 | 12~17 | 35~40 | 50~70 | 52~72 | ||||||
| 80~100 | 15 | 15~30 | 50 | 80~100 | 82~102 | ||||||
| 1.5 | 20~26 | 12 | 12~17 | 24~32 | 30~39 | 33~42 | 12 | 12 | 24 | ||
| 28~44 | 15 | 15~30 | 36~50 | 42~67.5 | 45~70.5 | ||||||
| 45~52 | 18 | 18~40 | 50~60 | 72~78 | 75~81 | ||||||
| 60~100 | 20 | 20-50 | 60~70 | 90~150 | 93·153 | ||||||
| 2.0 | 15~18 | 12 | 12~17 | 24~30 | 30~36 | 34~40 | 16 | 13 | 29 | ||
| 20~28 | 15 | 15·22 | 32~45 | 40~56 | 44~60 | ||||||
| 30~36 | 18 | 18~40 | 50 | 60~72 | 64~76 | ||||||
| 40~48 | 20 | 20~44 | 60 | 80~96 | 84~100 | ||||||
| 50~100 | 25 | 25~60 | 60~100 | 100~200 | 104~204 | ||||||
| 2.5 | 15~18 | 15 | 15~30 | 30~38 | 37.5~45 | 42.5~50 | 20 | 14 | 34 | ||
| 20~24 | 18 | 18~40 | 40~48 | 50~60 | 55~65 | ||||||
| 25~36 | 20 | 20~50 | 50~70 | 62.5~90 | 67.5~95 | ||||||
| 40~60 | 25 | 25~70 | 70~80 | 90~150 | 95~155 | ||||||
| 3.0 | 15~18 | 18 | 18~22 | 36~40 | 45~54 | 51~60 | 25 | 16 | 4 | ||
Related Products
| Plastic Gear | ||
 |
 |
 |
| Worm Gear and Worm | ||
 |
 |
 |
 |
 |
 |
| Bevel Gear | ||
 |
 |
 |
 |
 |
 |
| Chain Gear | ||
 |
 |
 |
