Timing Belt Pulley HTD5M Type
Timing pulleys have teeth or grooves around the diameter of the pulley body. A specialized design maintains accurate timing by locking the pulley into the system using a belt with similar teeth and grooves. This allows the two axes of rotation to be locked together, allowing them to rotate continuously at the same speed and maintain positional alignment for the system’s lifetime.
Timing Belt Pulley HTD5M Type
Timing Belt Pulley HTD5M Type has teeth or grooves around the diameter of the pulley body. A specialized design maintains accurate timing by locking. The pulley into the system using a belt with similar teeth and grooves. This allows the two axes of rotation to be locked together, allowing them to rotate continuously at the same speed and maintain positional alignment for the system’s lifetime.
Parameters
HTD 5M 09 Pitch 5.00 mm – Belt Width 9.00 mm
| Pulley Designation | Type | PCD (mm) | De (mm) | Df (mm) | Dm (mm) | F | L | Stock Bore | Material | Flanges |
| 112-5M-09 | 16F | 19.10 | 17.96 | 23.00 | 13.00 | 14.50 | 20.00 | 4.00 | Steel | Y |
| 114-5M-09 | 16F | 22.28 | 21.14 | 25.00 | 14.00 | 14.50 | 20.00 | 6.00 | Steel | Y |
| 115-5M-09 | 16F | 23.87 | 22.73 | 28.00 | 16.00 | 14.50 | 20.00 | 6.00 | Steel | Y |
| 116-5M-09 | 16F | 25.46 | 24.32 | 28.00 | 16.50 | 14.50 | 20.00 | 6.00 | Steel | Y |
| 118-5M-09 | 16F | 28.65 | 27.51 | 32.00 | 20.00 | 14.50 | 20.00 | 6.00 | Steel | Y |
| 120-5M-09 | 16F | 31.83 | 30.69 | 36.00 | 23.00 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 121-5M-09 | 16F | 33.42 | 32.28 | 38.00 | 24.00 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 122-5M-09 | 16F | 35.01 | 33.87 | 38.00 | 25.50 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 124-5M-09 | 16F | 38.20 | 37.06 | 42.00 | 27.00 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 126-5M-09 | 16F | 41.38 | 40.24 | 44.00 | 30.00 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 128-5M-09 | 16F | 44.56 | 43.42 | 48.00 | 30.50 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 130-5M-09 | 16F | 47.75 | 46.60 | 51.00 | 35.00 | 14.50 | 22.50 | 6.00 | Steel | Y |
| 132-5M-09 | 16F | 50.93 | 49.79 | 54.00 | 38.00 | 14.50 | 22.50 | 8.00 | Steel | Y |
| 136-5M-09 | 16F | 57.30 | 56.16 | 60.00 | 38.00 | 14.50 | 22.50 | 8.00 | Steel | Y |
| 140-5M-09 | 16F | 63.66 | 62.52 | 71.00 | 38.00 | 14.50 | 22.50 | 8.00 | Steel | Y |
| 44-5M-09 | 6 | 70.03 | 68.89 | – | 38.00 | 14.50 | 25.50 | 8.00 | Aluminum | N |
| 48-5M-09 | 6 | 76.39 | 75.25 | – | 38.00 | 14.50 | 25.50 | 8.00 | Aluminum | N |
| 60-5M-09 | 6W | 95.49 | 94.35 | – | 50.00 | 14.50 | 25.50 | 8.00 | Aluminum | N |
| 72-5M-09 | 6W | 114.59 | 113.45 | – | 50.00 | 14.50 | 25.50 | 8.00 | Aluminum | N |
| 80-5M-09 | 6A | 127.32 | 126.18 | – | 62.00 | 14.50 | 25.50 | 12.00 | Aluminum | N |
| 90-5M-09 | 6A | 143.24 | 142.10 | – | 62.00 | 14.50 | 25.50 | 12.00 | Aluminum | N |
| 112-5M-09 | 6A | 178.25 | 177.11 | – | 62.00 | 14.50 | 25.50 | 12.00 | Aluminum | N |
HTD 5M 15 Pitch 5.00 mm – Belt Width 15.00 mm
| Pulley Designation | Type | PCD (mm) | De (mm) | Df (mm) | Dm (mm) | F | L | Stock Bore | Material | Flanges |
| 112-5M-15 | 16F | 19.10 | 17.96 | 23.00 | 13.00 | 20.50 | 26.00 | 4.00 | Steel | Y |
| 114-5M-15 | 16F | 22.28 | 21.14 | 25.00 | 14.00 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 115-5M-15 | 16F | 23.87 | 22.73 | 28.00 | 16.00 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 116-5M-15 | 16F | 25.46 | 24.32 | 28.00 | 16.50 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 118-5M-15 | 16F | 28.65 | 27.51 | 32.00 | 20.00 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 120-5M-15 | 16F | 31.83 | 30.69 | 36.00 | 23.00 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 121-5M-15 | 16F | 33.42 | 32.28 | 38.00 | 24.00 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 122-5M-15 | 16F | 35.01 | 33.87 | 38.00 | 25.50 | 20.50 | 26.00 | 6.00 | Steel | Y |
| 124-5M-15 | 16F | 38.20 | 37.06 | 42.00 | 27.00 | 20.50 | 28.00 | 6.00 | Steel | Y |
| 126-5M-15 | 16F | 41.38 | 40.24 | 44.00 | 30.00 | 20.50 | 28.00 | 6.00 | Steel | Y |
| 128-5M-15 | 16F | 44.56 | 43.42 | 48.00 | 30.50 | 20.50 | 28.00 | 6.00 | Steel | Y |
| 130-5M-15 | 16F | 47.75 | 46.60 | 51.00 | 35.00 | 20.50 | 28.00 | 6.00 | Steel | Y |
| 132-5M-15 | 16F | 50.93 | 49.79 | 54.00 | 38.00 | 20.50 | 28.00 | 8.00 | Steel | Y |
| 136-5M-15 | 16F | 57.30 | 56.16 | 60.00 | 38.00 | 20.50 | 28.00 | 8.00 | Steel | Y |
| 140-5M-15 | 16F | 63.66 | 62.52 | 71.00 | 38.00 | 20.50 | 28.00 | 8.00 | Steel | Y |
| 44-5M-15 | 6 | 70.03 | 68.89 | – | 38.00 | 20.50 | 30.00 | 8.00 | Aluminum | N |
| 48-5M-15 | 6 | 76.39 | 75.25 | – | 38.00 | 20.50 | 30.00 | 8.00 | Aluminum | N |
| 60-5M-15 | 6W | 95.49 | 94.35 | – | 50.00 | 20.50 | 30.00 | 8.00 | Aluminum | N |
| 72-5M-15 | 6W | 114.59 | 113.45 | – | 50.00 | 20.50 | 30.00 | 8.00 | Aluminum | N |
| 80-5M-15 | 6A | 127.32 | 126.18 | – | 62.00 | 20.50 | 30.00 | 12.00 | Aluminum | N |
| 90-5M-15 | 6A | 143.24 | 142.10 | – | 62.00 | 20.50 | 30.00 | 12.00 | Aluminum | N |
| 112-5M-15 | 6A | 178.25 | 177.11 | – | 62.00 | 20.50 | 30.00 | 12.00 | Aluminum | N |
HTD 5M 25 Pitch 5.00 mm – Belt Width 15.00 mm
| Pulley Designation | Type | PCD (mm) | De (mm) | Df (mm) | Dm (mm) | F | L | Stock Bore | Material | Flanges |
| 112-5M-25 | 16F | 19.10 | 17.96 | 23.00 | 13.00 | 30.00 | 36.00 | 4.00 | Steel | Y |
| 114-5M-25 | 16F | 22.28 | 21.14 | 25.00 | 14.00 | 30.00 | 36.00 | 6.00 | Steel | Y |
| 115-5M-25 | 16F | 23.87 | 22.73 | 28.00 | 16.00 | 30.00 | 36.00 | 6.00 | Steel | Y |
| 116-5M-25 | 16F | 25.46 | 24.32 | 28.00 | 16.50 | 30.00 | 36.00 | 6.00 | Steel | Y |
| 118-5M-25 | 16F | 28.65 | 27.51 | 32.00 | 20.00 | 30.00 | 36.00 | 6.00 | Steel | Y |
| 120-5M-25 | 16F | 31.83 | 30.69 | 36.00 | 23.00 | 30.00 | 36.00 | 6.00 | Steel | Y |
| 121-5M-25 | 16F | 33.42 | 32.28 | 38.00 | 24.00 | 30.00 | 38.00 | 6.00 | Steel | Y |
| 122-5M-25 | 16F | 35.01 | 33.87 | 38.00 | 25.50 | 30.00 | 38.00 | 6.00 | Steel | Y |
| 124-5M-25 | 16F | 38.20 | 37.06 | 42.00 | 27.00 | 30.00 | 38.00 | 6.00 | Steel | Y |
| 126-5M-25 | 16F | 41.38 | 40.24 | 44.00 | 30.00 | 30.00 | 38.00 | 6.00 | Steel | Y |
| 128-5M-25 | 16F | 44.56 | 43.42 | 48.00 | 30.50 | 30.00 | 38.00 | 6.00 | Steel | Y |
| 130-5M-25 | 16F | 47.75 | 46.60 | 51.00 | 35.00 | 30.00 | 38.00 | 6.00 | Steel | Y |
| 132-5M-25 | 16F | 50.93 | 49.79 | 54.00 | 38.00 | 30.00 | 38.00 | 8.00 | Steel | Y |
| 136-5M-25 | 16F | 57.30 | 56.16 | 60.00 | 38.00 | 30.00 | 38.00 | 8.00 | Steel | Y |
| 140-5M-25 | 16F | 63.66 | 62.52 | 71.00 | 38.00 | 30.00 | 38.00 | 8.00 | Steel | Y |
| 44-5M-25 | 6 | 70.03 | 68.89 | – | 38.00 | 30.00 | 40.00 | 8.00 | Aluminum | N |
| 48-5M-25 | 6 | 76.39 | 75.25 | – | 38.00 | 30.00 | 40.00 | 8.00 | Aluminum | N |
| 60-5M-25 | 6W | 95.49 | 94.35 | – | 50.00 | 30.00 | 40.00 | 8.00 | Aluminum | N |
| 72-5M-25 | 6W | 114.59 | 113.45 | – | 50.00 | 30.00 | 40.00 | 8.00 | Aluminum | N |
| 80-5M-25 | 6A | 127.32 | 126.18 | – | 62.00 | 30.00 | 40.00 | 12.00 | Aluminum | N |
| 90-5M-25 | 6A | 143.24 | 142.10 | – | 62.00 | 30.00 | 40.00 | 12.00 | Aluminum | N |
| 112-5M-25 | 6A | 178.25 | 177.11 | – | 62.00 | 30.00 | 40.00 | 12.00 | Aluminum | N |
What is a Timing Belt Pulley Used For?
Designed in a variety of ways to suit a variety of applications. Usually, pulley belts are smooth and are responsible for power transmission between components. The belt creates friction along the (typically ribbed) surface of the pulley, which causes the gear body to rotate. Conventional drive belts allow asynchronous, variable-speed operation. However, ribbed horizontal surfaces come with slippage and time risks.
Timing belt pulleys – also known as timing belt systems – are primarily working to align the movement of multiple gear shafts. Synchronized systems generally last longer and emit less noise than gear or chain drive units.
Timing belt pulleys are used in systems that require speed. They can be found in various applications, including engines, automation equipment, printers, and other mechanical devices. Teeth in the timing belt pulley help keep the timing belt adequately aligned, preventing it from slipping off the track.
Why Choose Our Timing Belt Pulley?
Timing pulleys are widely working in various equipment where the timing of both drives is precious, and the display ratio is essential. A timing pulley’s benefit is eliminating slippage and maintaining constant angular velocity. Timing pulleys are making according to the international and national standards with carbon steel/alloy steel/aluminum and hardened teeth to provide long life.
Known for superior sturdiness, dimensional accuracy, and durability, the offered range is working in compliance with industry norms and guidelines. Further, we provide these components in various customized forms according to patrons’ specific requirements. Apart from this, our quality controllers will test these pulleys’ quality on different parameters.
1) Warranty: our timing pulley’s quality is excellent, and with insurance within one year, when you receive the products and find quality problems, we promise you could return it and free maintenance.
2) Drawings: please send your timing pulleys’ drawings to us to get the best quotation; If you have no drawings, please get in touch with us, then we can work out CAD drawings and the best reference for you ASAP.
3) Sample: we accept one-piece sample orders. We could do examples according to your samples or drawings.
4) Confidentiality agreement: Strictly adherence to client confidentiality agreement for timing pulleys.
