Timing Belt Pulley L Type
Timing belt pulleys(Timing Belt Pulley L Type) connect and synchronize the rotation between two shaft systems. Automobiles, for example, use a timing belt pulley component to link the cam and crankshafts. The gear body of the pulley is lined with teeth that ensure the shafts do not slip. By directly coordinating the rotary motion of each shaft, the engine valves can open and close in proper timing and sequence.
Timing Belt Pulley L Type Products Description
| Product Name | Timing Belt Pulley | |
| Teeth profile | Trapezoidal toothed | MXL, XXL, XL, L, H, XH, XXH |
| T-toothed | T2.5, T5, T10, T20 | |
| Arc toothed | HTD3M, HTD5M, HTD8M, HTD14M, HTD20M, Gt2, Gt3, Gt5 | |
| S-toothed | S2M, S3M, S4.5M, S5M, S8M, S14M | |
| Parabolic-toothed | P2M, P3M, P5M, P8M, P14M | |
| Y-toothed | G2M, G3M, G5M, Y8M | |
| Teeth Quantity | 10-150 teeth or customized | |
| Inner Bore | 2-200mm H7 precision or customized | |
| Belt width | 4mm, 6mm, 9mm, 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm, 1/4”, 5/16”, 3/8”, 1/2”, 3/4”, 1”, 1.5”, 2”or customized | |
| Accessories | We can provide the service of assembling setscrews, bearings, shafts, or taper bush. | |
| Surface treatment | Anodize, Black Oxide, Phosphate, and Galvanization | |
| Drawing Format | Timing belt pulley cad drawing, timing belt pulley UG drawing, Timing belt Pulley Soilwork drawing, Timing Pulley PDF drawing | |
Timing Pulley Characteristic
- Accurate transmission, no sliding, constant transmission ratio;
- Smooth transmission, buffer, damping capacity, low noise;
- Efficient, up to 0.98,energy conservation;
- Convenient maintenance, no lubrication required, low maintenance cost;
Advantages of Timing Belt Pulley
Timing belt pulleys are available with lots of advanced features. Hence these pulleys are widely used in various industrial sectors such as textile, paper making, printing machinery, agriculture, and more. So, the advantages that are mainly available from these pulleys are mentioned below.
- These are available with high torque carrying capacity
- These are robust construction, so there will be no slipping between the belt and the pulley.
- These help in transmitting the power at a constant speed.
- Timing belt pulleys are available at a high strength
- These are resistant to corrosion and available with features for low noise and vibration
- Another essential advantage of this pulley is that it possesses a long life.
- These pulleys are available in the market in varied sizes and models.
