WD112 WDH112 Chain Sprockets
WD112 WDH112 Chain Sprockets will work with both WD112 and WDH112 welded steel drag chains. This WD112 sprocket is manufactured using a high quality steel and to precise specifications to ensure the best performance and a long working life. We can supply this sprocket with the standard configuration or the flanged configuration.
|
Sprocket Number | Pitch | Number of Teeth | Pitch Diameter | Maximum Bore | Shroud Diameter | Tooth Face |
---|---|---|---|---|---|---|
WD112-6 | 8.00″ | 6 | 16.00″ | 5-15/16″ | 12.36″ | 9.00″ |
WD112-7 | 8.00″ | 7 | 18.44″ | 5-15/16″ | 15.114″ | 9.00″ |
WD112-8 | 8.00″ | 8 | 20.90″ | 5-15/16″ | 17.812″ | 9.00″ |
WD112-9 | 8.00″ | 9 | 23.39″ | 5-15/16″ | 20.366″ | 9.00″ |
We also offer a full range of both precision roller chain and engineered.
Applications are varied and range from conveyor, elevator transfer to broad general industrial power transmission specialty applications with attachments and/or special materials are also available.
